Description

The KBPC 5010 Bridge Rectifier Diode 50A 1000V is a high-performance, heavy-duty bridge rectifier designed for use in high-power applications that require reliable AC to DC conversion. This rectifier diode is engineered to handle large currents and high voltages, making it ideal for industrial machinery, power supplies, and other demanding electronic systems.

Key Features:

• Current Rating: Capable of handling up to 50A, suitable for high-current applications and power conversion in heavy-duty systems.
• High Reverse Voltage: With a peak reverse voltage of 1000V, it ensures stable performance even under high-voltage conditions, making it ideal for various industrial applications.
• Bridge Rectifier Configuration: The diode features a bridge arrangement of four diodes, providing efficient full-wave rectification to convert AC to DC.
• Low Forward Voltage Drop: This minimizes energy loss during rectification, increasing the efficiency of the system and reducing heat generation.
• Durability: Designed to withstand electrical, thermal, and mechanical stresses, ensuring long-lasting performance in harsh conditions.
• Compact Design: Despite its high current rating, the KBPC 5010 maintains a compact form, making it easy to integrate into various circuit configurations.

Technical Specifications:

• Maximum Recurrent Peak Reverse Voltage (Vrrm): 1000V
• Average Forward Current (If(av)): 50A
• Forward Voltage Drop (Vf): ≤ 1.1V at 50A
• Maximum Reverse Current (Ir): ≤ 5μA at 25°C
• Operating Temperature Range: -55°C to +150°C
• Package Type: KBPC (Bridge Rectifier Package)

Applications:

• Power supply circuits for high-current DC output
• AC to DC conversion in industrial and commercial machinery
• Battery charging systems, especially for large-capacity batteries
• Freewheeling diodes in motor drive circuits
• High-efficiency power supplies for automotive and heavy-duty applications

Why Choose KBPC 5010 Bridge Rectifier Diode?

The KBPC 5010 Bridge Rectifier Diode is the ideal solution for high-power applications requiring reliable, efficient full-wave rectification. With its ability to handle 50A of current and 1000V of reverse voltage, it is perfect for industrial-grade power supplies, heavy machinery, and battery charging systems. The diode’s low forward voltage drop and exceptional durability ensure high efficiency and long-lasting performance, making it a dependable choice for demanding electronic systems in various applications.
