Description

The KBPC 1510 Bridge Rectifier Diode 15A 1000V is a high-performance, heavy-duty bridge rectifier designed for high-power AC to DC conversion applications. Ideal for use in power supplies, battery charging systems, and industrial equipment, this diode offers exceptional reliability and performance in demanding environments.

Key Features:

• Current Rating: Capable of handling up to 15A, making it suitable for high-power applications.
• High Reverse Voltage: With a peak reverse voltage of 1000V, it is designed to handle high-voltage conditions, ensuring safety and long-lasting performance.
• Bridge Rectifier Configuration: This component incorporates four diodes configured in a bridge arrangement for efficient full-wave rectification, converting AC voltage to DC with minimal loss.
• Low Forward Voltage Drop: Ensures efficient rectification with reduced energy loss, contributing to overall system efficiency.
• Durability: Built to withstand thermal, electrical, and mechanical stresses, ensuring reliability in industrial and commercial applications.
• Compact Design: The KBPC 1510's design allows for easy integration into various circuit configurations and saves space in larger power supply designs.

Technical Specifications:

• Maximum Recurrent Peak Reverse Voltage (Vrrm): 1000V
• Average Forward Current (If(av)): 15A
• Forward Voltage Drop (Vf): ≤ 1.1V at 15A
• Maximum Reverse Current (Ir): ≤ 5μA at 25°C
• Operating Temperature Range: -55°C to +150°C
• Package Type: KBPC (Standard bridge rectifier package)

Applications:

• Power supply circuits for high-current DC output
• AC to DC conversion in industrial equipment
• Battery charging systems
• Motor drive circuits and freewheeling diodes
• High-efficiency power supplies in consumer electronics and heavy machinery

Why Choose KBPC 1510 Bridge Rectifier Diode?

The KBPC 1510 Bridge Rectifier Diode is an ideal solution for high-power applications requiring reliable and efficient rectification. Its robust design and high current handling make it perfect for power supplies, industrial systems, and heavy-duty applications. Offering full-wave rectification and superior voltage handling, the KBPC 1510 ensures dependable performance in challenging environments, providing long-lasting and efficient conversion of AC to DC power.
